MPL4 Battery Charger

$3,520.00

Product code: MPL4

MPL4 Units will be available from May 2026. Pre-order now.

The MPL-4 Traction battery charger has been designed with the latest and future workshop standards in mind. Updates can be downloaded from our website and loaded using the supplied lead.

Suitable for most common battery types including LiFePO4, AGM, GEL and conventional lead acid.

The MPL-4 features a contactor reset mode for reactivating disabled/highly discharged LiFePO4 batteries.

This NEW model automatically adjusts current based on battery terminal temperature.

SPECIFICATION

INPUT: 110-230V AC

WEIGHT: 10lbs (4.5kg)

SIZE MPL4-BM (Desktop): 11 x 14.5 x 2.7 inches (280 x 369 x 70 mm)

SIZE MPL4-DT (Portable): 15 x 4.5 x 8.6 inches (380 x 115 x 220 mm)

SIZE MPL4-WM (Wall/Post Mount): 7.6 x 15 x 3 inches (193 x 380 x 77 mm)

Version:

Product code: MPL4

MPL4 Units will be available from May 2026. Pre-order now.

The MPL-4 Traction battery charger has been designed with the latest and future workshop standards in mind. Updates can be downloaded from our website and loaded using the supplied lead.

Suitable for most common battery types including LiFePO4, AGM, GEL and conventional lead acid.

The MPL-4 features a contactor reset mode for reactivating disabled/highly discharged LiFePO4 batteries.

This NEW model automatically adjusts current based on battery terminal temperature.

SPECIFICATION

INPUT: 110-230V AC

WEIGHT: 10lbs (4.5kg)

SIZE MPL4-BM (Desktop): 11 x 14.5 x 2.7 inches (280 x 369 x 70 mm)

SIZE MPL4-DT (Portable): 15 x 4.5 x 8.6 inches (380 x 115 x 220 mm)

SIZE MPL4-WM (Wall/Post Mount): 7.6 x 15 x 3 inches (193 x 380 x 77 mm)



  • The MPL-4 features a contactor reset mode for reactivating disabled/highly discharged LiFePO4 batteries.

    MPL-4 comes with with a sensing lead set allowing the ultimate in efficient charging. MPL-4 also features a constant output mode for battery support functionality at up to 125A.

  • MPL-4 is available in shelf, ramp and portable versions.

    3 versions:

    Bench Mount

    Portable/Desktop (coming soon)

    and Wall/Post Mount

  • MPL-4 meets the requirements of Mercedes Benz W 000 588 07 81 00 Charger specification.

    JLRSST151 APPROVED PRODUCT
